Custom Valve Solutions: Material Handling and Conveyors
Humphrey was the first to develop a material handling device that effectively integrates pneumatic, electrical and electronic zone control mechanisms. This innovative solution enables original equipment manufacturers and end-users alike to minimize installation and labor time, and maximize conveyor control alternatives.
Humphrey was also the first to integrate electronics to achieve brake, clutch, dual-zone sensing and sleep control functionality. Given our industry expertise and extensive product catalog, Humphrey is a valuable outsourcing partner for your pneumatic material handling needs.
In operation, cartons pass over belt-driven cam rollers. A metered restriction in the N740A valve body limits the depletion of the air bag. The spring tensioner reactivates the valve before the drive disengages, and replenishes the bag.
When the carton stops on the cam roller, the Humphrey N740A valve is held open long enough to exhaust the air bag. This disengages the drive belt from the rollers, and creates a cascade effect along the entire conveyor line.
In operation, cartons pass over belt-driven cam rollers. A metered restriction in the N740A valve body limits the depletion of the air bag. The spring tensioner reactivates the valve before the drive disengages, and replenishes the bag.
When the carton stops on the cam roller, the Humphrey N740A valve is held open long enough to exhaust the air bag. This disengages the drive belt from the rollers, and creates a cascade effect along the entire conveyor line.
Humphrey’s custom valve modules provide actuator control to divert product on a custom designed conveyor system.
A manufacturer of custom materials handling conveyor systems wanted to reduce costs, enhance performance, improve functionality, and reduce size. Humphrey designed a manifold body that provided a unique, contemporary look while reducing material costs.
Pallets are transported on a series of parallel roller chains, which are supported by inflated air bags. Air bags in each "zone" are kept inflated by air flowing through a "normally open" valve. When a pallet is oriented the wrong way, the edge contacts a sensor arm. The arm is forced down onto the actuator plunger in the valve. This simultaneously diverts the airflow and quickly exhausts the air bag, lowering the chain and stopping the pallet.
A conveyor manufacturer’s plastic valve with multiple components is a potential source of problems. Humphrey designed a single metal valve assembly to deliver improved reliability and superior performance.
Humphrey’s custom pendant control system enables addition of more than two buttons. This eliminates the need to mount a remote function button elsewhere on the equipment.
A manufacturer of air balancing equipment wanted to enhance its existing control handle. Humphrey redesigned the manifold assembly to achieve lighter actuation force and more reponsive metering.
Humphrey’s custom pendant control system enables addition of more than two buttons. This eliminates the need to mount a remote function button elsewhere on the equipment.
A manufacturer of air balancing equipment wanted to enhance its existing control handle. Humphrey redesigned the manifold assembly to achieve lighter actuation force and more reponsive metering.
Evolution of a Custom Control Valve Enhances Conveyor System Operation
