| Media | Glue with mild solvents |
| Valve Function | Air pilot w/ suck back, Normally Closed |
| Piping Type | Inline, Direct Piping |
| Port Size | 1/8 NPSF |
| Number of Ports | 2 ports |
| Number of Positions | 2 positions |
| Size (in) HxWxD | 1.81 x 1.19 DIA |
| Type of Operation | Double Air Pilot |
| Flow - SCFM @ 100 psig | 22 |
| Flow - LPM @ 6.9 bar | 623 |
| ESEOD (orifice) - in (mm) | 0.129 (3.28) |
| Flow Coefficient (Cv) | 0.30 |
| Pressure Range (psi) | 1-35 |
At Valved Pressure of:
Recommended Pilot Pressure (psi): | | <=10 PSI | 20 PSI | 30 PSI | | 20 | 30 | 40 |
|
| Ambient Temperature Range (⁰F) | 30-150 |
| Wetted Materials | Brass, FKM |
| Weight (oz) | 5.5 |
